※ Utilizes the Japanese Keyence control system, servo motors, which are precise, efficient and stable.

※ Adopting an advanced fault removal system, capable of automatic detection for situations such as low air pressure, abnormal motor operation, or abnormal belt operation, and can automatically stop the machine when an anomaly occurs, displaying the cause of the fault, facilitating and quickly resolving the issue.

※ The most notable feature is that the adjustment is simple, the adjustment time is short, and it can significantly reduce the machine adjustment time.

※ The touch screen allows for adjusting the compression position, resulting in more precise and stable compression.

※ It can quickly switch products within a short period of time.

Parameters

Power supply:AC 220V 50/60Hz(one phase)

Pressure force:5 - 6 kgf (Requires clean air)

Function:Wire cutting, one side stripping, one side terminal crimping, one side piercing crimping

The spacing of the machinable plastic shells:1.5mm-2.54mm

Output:3000 pieces per hour (depending on the product)

Cutting length:50mm-1000mm

Cutting accuracy:1mm + cutting length × less than 0.1%

Machine dimension:2050*2000*1600mm(Without protrusions)
