※ Utilizes the Japanese Keyence control system, servo motors, which are precise, efficient and stable.

※ Adopting an advanced fault removal system, it can automatically detect situations such as low air pressure, abnormal motor operation, and abnormal belt condition. In case of any anomaly, it can automatically stop the machine and display the cause of the fault, facilitating and quickly resolving the problem.

※ The best feature is that the adjustment is simple, the adjustment time is short, and it can significantly reduce the machine adjustment time.

※ The touch screen allows for adjusting the compression position, making the compression more precise and stable.

※ It can quickly switch products within a short period of time.

Parameters

Power supply: AC 220V 50/60Hz(one phase)

Pressure force::5 - 6 kgf (Requires clean air)

Function:Wire cutting, single end stripping, single end terminal crimping, single end piercing crimping

The spacing of the machinable plastic shells:1.5mm-2.54mm

Production capacity:1000 PCS/HOUR (depending on the product)

Cutting length:50mm-1000mm

Cutting accuracy:1mm + cutting length × less than 0.1%

Size:1900*2050*1900mm(Without protrusions)
