※ Material loading by vibration disc, convenient and fast.

※ Laser detection for both sides, convenient and accurate material selection.

※ Adopting computerized automatic detection, when there are situations such as low air pressure, abnormal motor, or abnormal belt, it can automatically stop and display the cause of the fault, making it convenient and quick to troubleshoot.

※ The best feature is simple adjustment, short adjustment time, and can significantly reduce the machine adjustment time.

※ Touchscreen for adjusting the compression position, making the compression terminals more precise and stable.

※ It can quickly switch products within a short period of time.

eters

Power supply: AC220V/50/60Hz(one phase)

Pressure force: 5-6 kgf (Requires clean air)

Function:Piercing and crimping

Processing range:2P-20P

Production capacity:3600 PCS/hour (depending on the product)

Crimping accuracy:±0.01mm

Size:780*740*1400mm(Without protrusions)
