※ Utilizes the French Schneider control system and servo motors, which are precise, efficient and stable.

※ Adopting an advanced fault removal system, capable of automatic detection for situations such as low air pressure, abnormal motor operation, and abnormal belt operation, and can automatically stop the machine when an anomaly occurs, displaying the cause of the fault, making it convenient and quick to troubleshoot.

※ The best feature is that the adjustment is simple, the adjustment time is short, and it can significantly reduce the machine adjustment time.

※ The touch screen allows for adjusting the crimping position, resulting in more precise and stable crimping.

※ It can quickly switch products within a short period of time.

Parameters

Power supply:AC220V 50/60Hz(one phase)

Pressure force:5-6 kgf (requires clean air)

Function:Wire cutting, one side crimping, two sides crimping, (either positive or reverse crimping)

The spacing of the machinable plastic shells:1.5mm-2.54mm

Production Capacity:4000 pieces per hour (depending on the product)

Cutting length:50mm-1000mm

Cutting accuracy:1mm + cutting length × less than 0.1%

Size:1050*650*1200mm(excluding protrusions)
